氣動閥門的介紹
Introduction to Pneumatic Valves
1、檢查氣動閥的型號和參數是否滿足現場安裝需要和技術要求。
1. Check whether the model and parameters of the pneumatic valve meet the on-site installation needs and technical requirements.
2、檢查氣缸和氣動閥的位置指示器，確保沒有損壞。
2. Check the position indicators of the cylinders and pneumatic valves to ensure they are not damaged.
3、清洗、吹掃氣動閥管路;如果介質中有雜質，應在閥門前面的管道上安裝過濾閥。
3. Clean and purge the pneumatic valve pipeline; If there are impurities in the medium, a filter valve should be installed on the pipe in front of the valve.
4、按氣動閥體上箭頭指示的方向安裝(下游安裝)，將氣動閥接口與管道連接，并確保連接密封良好。
4. Install in the direction indicated by the arrow on the pneumatic valve body (downstream installation), connect the pneumatic valve interface to the pipeline, and ensure that the connection and sealing are good.
5、如果安裝了電磁閥，注意確保接頭密封良好。
5. If a solenoid valve is installed, take care to ensure that the connector is properly sealed.
6、當需要焊接連接時，高溫不得傳遞到氣動閥的填料上。
6. When welding connections are required, high temperatures must not be transmitted to the packing of pneumatic valves.
氣動閥門和電磁閥安裝注意事項
Precautions for installation of pneumatic and electromagnetic valves
1、確保流體和氣源清潔，防止堵塞電磁閥或氣缸活塞。
1. Ensure that the fluid and air supply are clean to prevent clogging of the solenoid valve or cylinder piston.
2、電磁閥線圈帶電，正常運行時熱量高。不要觸摸它。
2. The solenoid valve coil is energized and has high heat during normal operation. Don't touch it.
3、電磁閥線圈充電時，禁止拆卸，以防觸電。
3. When charging the solenoid valve coil, it is prohibited to disassemble it to prevent electric shock.
4、嚴禁撞擊、碰撞電磁閥的線圈、插座、電磁管及連接部位，以免損壞。
4. It is strictly prohibited to hit or collide with the coil, socket, electromagnetic tube, and connection parts of the electromagnetic valve to avoid damage.
5、電磁閥線圈充電時，嚴禁將其蓋住，以防過熱和燃燒。
5. When charging the solenoid valve coil, it is strictly prohibited to cover it to prevent overheating and combustion.
電磁閥的實際電源電壓不得超過公差范圍。
The actual supply voltage of the solenoid valve must not exceed the tolerance range.
7、介質的工作壓力、溫度和粘度不得超過規定范圍。
7. The working pressure, temperature, and viscosity of the medium must not exceed the specified range.
This article is organized and released by Lianggong Valve. Do you have any understanding of these contents? For more information, please click: http://m.cqnk12580.net We will have more exciting content waiting for you to check.
